10MM Plastic dc motor

1. Model: HSP10MM
2. Rated Voltage: 3.0-24 V
3. No Load Speed: 20-4318 rpm
4. No Load Current: 60-80 mA
5. Rated Load Speed: 18-3625 rpm
6. Rated Load Current: 215-220 mA
  • Description
  • Reviews (0)

Description

micro dc motor
Performance Parameter:
Model Application Parameters Rated Torque of Gear Box Instant Torque of Gear Box Gear Ratio Gear Box Length
Rated At No Load At Rated Load Overall Length
Voltage Speed Current Speed Current Torque
VDC rpm mA rpm mA gf.cm mN.m mm gf.cm gf.cm mm
ZWBPD010010-3 3.0 4318 60 3625 215 6 0.6 24.7 1300 4000 4 9.7
ZWBPD010010-5 3.0 2879 60 2417 215 10 0.9 1300 4000 6
ZWBPD010010-13 3.0 1329 70 1115 215 17 1.6 27.8 1300 4000 13 12.8
ZWBPD010010-19 3.0 909 70 763 215 24 2.4 1300 4000 19
ZWBPD010010-28 3.0 617 70 518 215 36 3.5 1300 4000 28
ZWBPD010010-46 3.0 375 80 315 215 39 3.8 30.9 1300 4000 46 15.9
ZWBPD010010-69 3.0 250 80 210 215 58 5.7 1300 4000 69
ZWBPD010010-102 3.0 169 80 142 215 86 8.4 1300 4000 102
ZWBPD010010-151 3.0 114 80 96 215 127 12.5 1300 4000 151
ZWBPD010010-168 3.0 98 80 86 220 106 10.4 34 1300 4000 168 19
ZWBPD010010-249 3.0 66 80 58 220 158 15 1300 4000 249
ZWBPD010010-368 3.0 45 80 39 220 233 23 1300 4000 368
ZWBPD010010-546 3.0 30 80 27 220 346 34 1300 4000 546
ZWBPD010010-809 3.0 20 80 18 220 512 50 1300 4000 809
*above specifications are subject to change without notice, just for reference and customizable according to requirements.
